High Quality Ceramic Fiber Blanket Insulation Refractory Ceramic Wool Fiber Blanket

Chat

publisher:河北华欧节能科技集团有限公司

Description

Product Description

Ceramic wool is a high-strength, needled insulating blanket that is made from wool bulk. The combination of long spun fibers and needling operation produce tough, resilient, and strong blankets, which resist tearing both before and after heating.
ceramic wool is completely inorganic and available in a variety of temperature grades densities and sizes. A ceramic wool blanket can be folded, compressed, and encapsulated to produce modules.

Standard Sizes

Classification Temperature: 1260℃-1430℃
Density: 64kg/m3, 96kg/m3, 128kg/m3
Thicknesses: 1″，1 1/2″, 2″
Standard Widths: 24″
Length: 30’

Features

*Excellent thermal shock resistance
*Excellent thermal stability
*High tensile strength
*Low thermal conductivity
*Low heat storage

Specification

item	value
Grade	COM (Common)
Application	Liners Of Industrial Furnace
Thickness	6mm-50mm
Width	100mm-1220mm
Length	3.6m-14.64m
Chemical Composition	Al2O3+SIO2≥99%
Ultimate Strength (≥ MPa)	0.5Mpa (25mm thickness)
Working Temperature	1050~1600 C.degree
Fiber Diameter	3-5μm
Shrinkage (1800 ℉, 3h)	1050~1600 C.degree
Thermal Conductivity	0.06-0.12
Density (kg/m³ )	128
Brand Name	Ecoin
Place of Origin	China
	Tianjin

Product Paramenters

Description
	STD BLANKET			HP BLANKET		HZ BLANKET
Classification Temperature (°C)	1260			1260		1430
Chemical Composition (%)
Al2O3	≥43			≥44		≥35
SiO2	≥54			≥55		≥49
ZrO2	-			-		≥15
Color	White			White		White
Shot Content (%)	≤15			≤15		≤12
Density(kg/m3)	64	96	128	96	128	96	128
Tensile Strength(Kpa)	30	50	70	50	70	50	70
Permanent Linear Shrinkage(%)	1000°Cx24h≤2.5			1100°Cx24h≤2.5		1350°Cx24h≤3.0
Thermal Conductivity(W/m.K)
200°C	0.07	0.06	0.06	0.06	0.06	0.06	0.06
400°C	0.12	0.11	0.1	0.11	0.1	0.11	0.1
600°C	0.2	0.19	0.18	0.19	0.17	0.16	0.15
800°C	0.3	0.23	0.2	0.23	0.2	0.21	0.19
1000°C	0.4	0.32	0.27	0.31	0.26	0.3	0.26
