closed cell PVC/NBR self adhesive rubber foam board sheet easily install building materials
closed cell PVC/NBR self adhesive rubber foam board sheet easily install building materials
1
Chat
publisher:河北华欧节能科技集团有限公司
Description
Product Description

Brief introduction of Rubber Foam

The rubber foam products of our company are produced by imported high-end technology and automatic continuous equipment. We have developed a rubber foam insulation material with excellent performance through in-depth research. The major raw materials we use are NBR/PVC.

The main characteristics are: low density, close and even bubble structure, low thermal conductivity, cold resistance, extremely low water vapor transmissibility, low water absorbtive capacity, great fireproof performance, superior anti-age performance, good flexibility, stronger tear strength, higher elasticity, smooth surface, no formaldehyde, shock absorption, sound absorption, easy to install. The product is suitable for a wide range of temperature from -40℃ to 120℃.
Our Class0/1 insulation is generally black in color, other colors are available upon request. The product comes in tube, roll and sheet form. The extruded flexible tube are specially designed to fit the standard diameters of copper, steel and PVC piping. Sheets are available in standards precut sizes or in rolls.
Specification of Rubber Foam

Technical Data
Item
Unit
Specification
Standard
Density range
Kg/m3
40-85
GB/T 6343
ASTM D1667
Flammability
Oxygen index
%
≥32
GB/T 2406
SDR
——
≤75
GB/T 8627
Fire Rating
——
Class 0 & Class 1
BS 476 Part 6 & Part 7
Conductivity factor
-Average temperature
-20℃
W/(M·K)
≤0.030
GB/T 10294
ASTM C518
0℃
≤0.032
40℃
≤0.036
Water vapor Permeability
Coefficient
g/(m·s·pa)
≤2.8 X 10-11
GB/T 17146
Factor
——
≥10000
Water adsorption ratio in vacuum
%
≤4
GB/T 17794
Dimension stability (105℃±3℃, 7d)
%
≤5
GB/T 8811
ASTM C534
Crack resistance
N/cm
≥3.0
GB/T 10808
Comperssion resilience ratio
(Comperssion ratio 50%, Comperssion time 72h)
%
≥70
GB/T 6669
Anti-ozone
(Ozone pressure 202mpa 200h)
——
Not cracking
GB/T 7762
Aging resistance (150h)
——
Slightly crumpling, no cracks, no pin holes, not eforming
GB/T 16259
Flexibility
——
Excellent
ASTM D1056
Temperature
-50 — 120
GB/T 17794
Products type
Pipe & sheet
Color
Black, gray and other colors
Regular size
Pipe: inner diameter 6-108mm
Sheet: thickness 10-30mm
Packing
PE plastic bags / exported standard carton
Diversified packaging to meet your needs
